PX Series - Pulse Oximetry LEDs

Optoelectronic components have been evolving in application usages ever since its inception. What started out as simple indicator lights for ON/OFF purposes eventually expanded to LEDs being used aesthetically, enhancing the product in ways beyond indication. SunLED has proudly been a leading manufacturer in each of these turning points in opto technology. Lighting the way towards the next chapter in LED evolution, SunLED introduces the PX Series - Pulse Oximetry LEDs.

SunLED's PX Series is available in various compact packages which are ideal for any medical or wearable device. This series comes in both single and dual wavelength package configurations. A variety of viewing angles are available to further provide design flexibility. Specific wavelengths of ?P=660nm and 940nm with narrow spectral bandwidths provide the perfect LED solution for pulse oximetry applications.

For a complete Sensor Application LED solution, SunLED's HRS Series are also readily available for Heart Rate Sensor applications.

Part No.Package SizeColorLensWavelengthOptical DataViewing AngleSpec3D Drawings
XZM2MR53W-11.6x0.8x0.75mm (0603)RedWater Clear660nm120198If=20mA160°
XZM2MR53W-81.6x0.8x0.95mm (PixsoLED)RedWater Clear660nm200317If=20mA60°
XZM2MR55W3.2x1.6x1.1mm (1206)RedWater Clear660nm120198If=20mA160°
XZM2MR55W-33.2x1.6x1.8mm (1206 Dome Lens LED)RedWater Clear660nm7001095If=20mA40°
XZM2MRTNI45SC2C3.5x2.8x1.9mm (PLCC4 Bi-Color)Red / IRWater Clear660nm / 940nm120 / 1.2228 / 2.3If=20mA120°
XZM2MRTNI55W-83.2x1.6x1.8mm (1206 Bi-Color Dome Lens LED)Red / IRWater Clear660nm / 940nm120 / 0.8397 / 1.3If=20mA30°
XZM2MRTNI59W-11.6x1.5x0.7mm (0606 Bi-Color)Red / IRWater Clear660nm / 940nm120 / 1.6198 / 2.8If=20mA150°
XZTNI53W-11.6x0.8x1.1mm (0603 IR)InfraredWater Clear940nm0.81.8If=20mA150°
XZTNI53W-81.6x0.8x0.95mm (PixsoLED)InfraredWater Clear940nm1.22.8If=20mA60°
XZTNI55W3.2x1.6mm (1206 Dome Lens IR)InfraredWater Clear940nm0.81.8If=20mA160°
XZTNI55W-33.2x1.6mm (1206 Dome Lens IR)InfraredWater Clear940nm24.8If=20mA50°
